NET-ROUTER-SIM Asus 4G-AC68U LTE (AC1900) ismertető Network Standard IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IPv4, IPv6 Product Segment AC1900 ultimate AC performance : 600+1300 Mbps Coverage Large homes Data Rate 802.11a : 6,9,12,18,24,36,48,54 Mbps802.11b : 1, 2, 5.5, 11 Mbps802.11g : 6,9,12,18,24,36,48,54 Mbps802.11n : up to 450 Mbps802.11n TurboQAM : up to 600 Mbps802.11ac : up to 1300 Mbps Connectivity Technology LTE: Downlink 300 Mbps / Uplink 50 MbpsHSPA+: Downlink 42.2 Mbps / Uplink 5.76 Mbps4G FDD-LTE: 800 /1800 /2100 /26004G TDD-LTE: 26003G UMTS: 900 /2100 Antenna External antenna x 2Internal 2dBi antenna x 1 for Wi-FiDetachable 3dBi antenna x 2 for Mobile Transmit/Receive MIMO technology2.4 GHz 3 x 35 GHz 3 x 3 Memory 128 MB Flash256 MB RAM Operating Frequency 2.4 GHz / 5 GHz Encryption 64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPS support Firewall & Access Control Firewall:SPI intrusion detection,DoS protectionAccess control:Parental control, Network service filter, URL filter, Port filter Management UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Universal Repeater, System Event Log VPN Support IPSec Pass-ThroughPPTP Pass-ThroughL2TP Pass-ThroughPPTP serverOpenVPN serverPPTP clientL2TP clientOpenVPN client WAN Connection Type Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TPMulticast Proxy supportMulticast Rate Setting support Ports RJ45 for 10/100/1000/Gigabits BaseT for LAN x 4, RJ45 for 10/100/1000/Gigabits BaseT for WAN x 1USB 3.0 x 1SIM Card x 1 Features Airtime FairnessTraffic AnalyzerAdaptive QoSSmartQoS- WMM- User definable rules for IP/MAC/Port- Upload and download bandwidth management- ACK/SYN/FIN/RST/ICMP with highest priorityAiProtectionParental ControlGuest Network : 2.4 GHz x 3, 5 GHz x 3VPN server : IPSec Pass-Through, PPTP Pass-Through, L2TP Pass-Through, PPTP Server, OpenVPN ServerVPN client : PPTP client, L2TP client, OpenVPN clientMac OS BackupEnhanced media server (AiPlayer app compatible)- Image : Jpeg- Audio : mp3, wma, wav, pcm, mp4, lpcm, ogg- Video : asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, movAiCloud personal cloud service3G/4G data sharingPrinter Server- Multifunctional printer support (Windows only)- LPR protocol supportDownload Master- Support bt, nzb, http, ed2k- Support encryption, DHT, PEX and magnet link- Upload and download bandwidth control- Download schedulingAiDisk file server- Samba and FTP server with account managementDual WANIPTV supportRoaming Assist Button WPS Button, Reset Button, Power Button, Wireless on/off Button LED Indicator Power x 1WAN x 1Wi-Fi x 2LAN x 1USB x 1WPS x 13G/4G signal x 4 Power Supply AC Input : 110V~240V(50~60Hz)DC Output : 19 V with max. 2.37 A current OS Support Windows® 10Windows® 8.1Windows® 8Windows® 7Windows® VistaWindows® 2000Windows® MEWindows® XPWindows® Server 2003Windows® Server 2008Mac OS X 10.1Mac OS X 10.4Mac OS X 10.5Mac OS X 10.6Mac OS X 10.7Mac OS X 10.8Mac OS XLinux Kernel (Support Ubuntu only)Linux Dimensions 247 x 76 x 168 ~ mm (WxDxH) (Without Bezel) Weight 795 g Color Black Router Special Features 3G/4G data sharing, AiCloud, Printer server, Download Master, AiDisK, Multiple SSIDs, Parental Control Operation mode Wireless router modeRange extender modeAccess point modeMedia bridge mode
